Description

Introduction

SLD Electrical Diagram APP is an application designed for engineers, electricians and technicians to create a single line diagram on their mobile phones. The app helps experts to solve and edit important electrical diagrams.

Furthermore it helps to arrange electrical components like transformers, circuit breakers and electrical conductors in a simple diagram.

project made in SLD Electrical Diagram APP
Single Line Diagram

How to use the SLD Electrical Diagram APP

The application simplifies electrical diagrams to view and understand electrical components. Here is the step-by-step guide to use this app.

  • Download and Install: The app is available on play store and you can also get it from Apkowner.net
  • Create account: After installing the app, create an account to use the app.
  • Navigate Interface: explore the interface and understand the menu.
  • New project: Tap on a new projector to start your Diagram.
  • Use Components: Add new components like transformers and other electrical components.
  • Use symbols: Select and place the symbols, it has also the option to see properties of any symbol.
  • Save the Document: Save the file on your devices and convert them in any file format like PDF, MS WORD or other E-Format.

Uses SLD Diagrams in Projects

SLD Diagrams are used in many projects and it is important to use them in power distribution in electric projects. Here are some key projects where you can use them.

Electric power generation and distribution projects

Power station, and transmission systems use SLD diagrams to distribute electricity in different areas.

Industrial projects

Large industries or factories used SLD Diagrams to ensure the safety of their equipment including Large motors, machines and control panels.

Commercial building electrical installation

In commercial building projects like Shopping malls, offices, and other building projectors, they use SLD Diagrams to design and  maintain electric layouts, from power distribution to lighting systems.

Renewable Electric projects

Renewable power stations use SLDs to map how electricity is generated and distributed through inverters and transformers.

Features

  1. Creating and Editing Diagram: LSD Diagram app helps professionals to create and edit Single Line Diagrams.
  1. Electrical Symbols: The Single Line Diagram app provides International electrical and electronics symbols in their application, which are used globally.
  1. Testing Demo Diagrams: The application has testing features In-Built, this feature helps experts to test their design before using or implementing it.
  1. Online and Off-line Feature: Some apps only work when the device is connected to an internet connection but this one works both ON-line and Off-line.
  2. Sharing and Exporting: The software allows sharing projects with others and it has the option to save files.
  1. Easy to Use: Its interface is easy to use and the featuring tools make it more easy to navigate.

Final Remark

The SLD app is a valuable tool for electrical engineers that make their work easy and simple. The app is helpful for students and engineers which makes projects in a short-time period. It’s easy to understand and also educates students on how to make a Single Line Diagram.
